CH104: Chemistry and the Environment

Chapter 5: Chemical Reactions

This content can also be downloaded as an printable PDF, adobe reader is required for full functionality.

This text is published under creative commons licensing, for referencing and adaptation, please click here.

Opening Essay

5.1 The Law of Conservation of Matter

5.2 Writing and Balancing Chemical Equations

Practice Writing and Balancing Equations

5.3 Quantitative Relationships Based on Chemical Equations

5.4 Some Types of Chemical Reactions

(1) Combination (or Synthesis) Reactions

(2) Decomposition Reactions

(3) Single Replacement (or Single Displacement) Reactions

(4) Double Replacement (or Displacement) Reactions

     Acid-Base Neutralization Reactions

     Precipitation Reactions

     Solubility Rules

     Net Ionic Equations

     Applications and Examples

(5) Oxidation and Reduction (Redox) Reactions

     Rules for Assigning Oxidation States

     Combustion Reactions

     A Closer Look at the Importance of Redox Reactions

5.5 Focus on the Environment – Air Pollution

5.6 Chapter Summary

5.7 References

---

Opening Essay

Although yeast has been used for thousands of years, its true nature has been known only for the last two centuries. Yeasts are single-celled fungi. About 1,000 species are recognized, but the most common species is Saccharomyces cerevisiae, which is used in bread making. Other species are used for the fermentation of alcoholic beverages. Some species can cause infections in humans.

Yeasts live primarily on sugars, such as glucose (C₆H₁₂O₆). They convert glucose into carbon dioxide (CO₂) and ethanol (C₂H₅OH) in a chemical transformation that is represented as follows:

C₆H₁₂O₆ (s) → 2CO₂(g) + 2C₂H₅OH(ℓ)

Bread making depends on the production of carbon dioxide. The gas, which is produced in tiny pockets in bread dough, acts as a leavening agent: it expands during baking and makes the bread rise. Leavened bread is softer, lighter, and easier to eat and chew than unleavened bread. The other major use of yeast, fermentation, depends on the production of ethanol, which results from the same chemical transformation. Some alcoholic beverages, such as champagne, can also be carbonated using the carbon dioxide produced by the yeast.

Figure 5.1 Yeast is used in many food processing applications. In bread making, the yeast, Saccharomyces cerevisiae, is often sold as a granulated dry form (A).  It is used to create leavened bread (B).

Photo of activated dry yeast is from:  Ranveig. Photo of leavened bread is from: 3268zauber

---

Yeast is among the simplest life forms on Earth, yet it is absolutely necessary for at least two major food industries. Without yeast to turn dough into bread and juice into wine, these foods and food industries would not exist today.

(Back to the Top)

---

5.1 The Law of Conservation of Matter

Chemical change is a central concept in chemistry. The goal of chemists is to know how and why a substance changes in the presence of another substance or even by itself. Because there are tens of millions of known substances, there are a huge number of possible chemical reactions. In this chapter, we will find that many of these reactions can be classified into a small number of categories according to certain shared characteristics.

In science, a law is a general statement that explains a large number of observations. Before being accepted, a law must be verified many times under many conditions. Laws are therefore considered the highest form of scientific knowledge and are generally thought to be inviolable. Scientific laws form the core of scientific knowledge.

One scientific law that provides the foundation for understanding in chemistry is the law of conservation of matter. It states that in any given system that is closed to the transfer of matter (in and out), the amount of matter in the system stays constant. A concise way of expressing this law is to say that the amount of matter in a system is conserved, or that matter cannot be created or destroyed during a chemical reaction.  It only changes form.

What does this mean for chemistry? In any chemical change, one or more initial substances change into a different substance or substances. Both the initial and final substances are composed of atoms because all matter is composed of atoms. According to the law of conservation of matter, matter is neither created nor destroyed, so we must have the same number and type of atoms after the chemical change as were present before the chemical change.

Before looking at explicit examples of the law of conservation of matter, we need to examine the method chemists use to represent chemical changes.

---

5.2 Writing and Balancing Chemical Equations

Water (H₂O) is composed of hydrogen and oxygen. Suppose we imagine a process in which we take some elemental hydrogen (H₂) and elemental oxygen (O₂) and let them react to make water. The chemical equation below is used to express this reaction:

In this chemical reaction, the chemical formulas of the reactants (or substrates) are written on the left side of the equation, and the chemical formulas of the products are written on the right side. A plus sign connects the initial substances (and final substances, if there is more than one), and an arrow (→) represents the chemical change (or reaction). In reactions, it is also common to include a phase label with each formula—(s) for solid, (ℓ) for liquid, (g) for gas, and (aq) for a substance dissolved in water, also known as an aqueous solution.

Due to the law of the conservation of matter, each chemical reaction needs to be balanced to ensure that the same number and types of atoms on the left side of the equation are the same as on the right side of the reaction. To represent this balance, coefficients are placed in front of the chemical formulas on each side to ensure that the same numbers and types of atoms are on each side of the equation. If the coefficient is one, it is not written into the equation, but is assumed. The coefficients represent how many molecules are present in the reaction. In this case, we can see that there are two H₂ molecules (or a total of four hydrogen atoms) of the left side of the equation and that there are two H₂O molecules, which also include four hydrogens on the right side of the equation. Likewise, there are two oxygen atoms in the form of one oxygen molecule (O₂) on the left side, and two oxygen atoms on the right side in the form or two water molecules. A diagram using the Lewis structures is shown below to represent the number of molecules indicated by the coefficients of the equation:

Figure 5.2 shows a rather dramatic example of this very reaction.

Figure 5.2 Chemical reactions can be violent in nature. When exposed to a spark or a flame, hydrogen and oxygen react violently to form water.  Here the hydrogen gas in the zeppelin, SS Hindenburg, reacts with the oxygen in the air to make water.

The Hindenburg Photo is made available from the US Navy.

(Back to the Top)

---

Practice Writing and Balancing Equations

To write proper chemical reactions, it is first necessary to write the correct chemical formulas.  As you have learned in Chapters 3 and 4, both ionic and covalent compounds combine to either donate/accept electrons or share electrons in ways that enable atoms to reach a stable state, most often following the octet rule. This should be the first consideration when writing a chemical reaction.The second consideration should be the states of the matter involved in the chemical reaction.  Label each as a solid (s), a liquid (ℓ), a gas (g), or an aqueous solution (aq). Once the correct chemical formulas have been established, proper chemical equations should then be balanced. Writing balanced reactions is a chemist’s way of acknowledging the law of conservation of matter.

How does one balance a chemical equation, starting with the correct formulas of the reactants and products? Basically, a back-and-forth approach is adopted, counting the number of atoms of one element on one side, checking the number of atoms of that element on the other side, and changing a coefficient if necessary. Then check another element, going back and forth from one side of the equation to another, until each element has the same number of atoms on both sides of the arrow. In many cases, it does not matter which element is balanced first and which is balanced last, as long as all elements have the same number of atoms on each side of the equation. However, if elemental forms appear in an equation (i.e. Na, Zn, O₂, H₂, Cl₂, etc), it is often easier to balance the equation, by leaving the elemental forms to be balanced last.

For example, to balance the equation:

CH₄ + Cl₂ → CCl₄ + HCl

the first thing that we notice, is that it contains the elemental form of chlorine (Cl₂).  That leaves carbon and hydrogen to balance. We might choose to count the carbon atoms first, finding that both sides are balanced with one carbon atom. Thus, we will not change the coefficient for the carbon-containing molecules, but instead shift our focus to the number of hydrogen atoms. The reactant side has four hydrogen atoms, however, the product side only has one hydrogen.  Thus, we will need to add a coefficient to the product side, such that the product side will also have four hydrogen atoms. We fix this by putting a 4 in front of the HCl:

CH₄ + Cl₂ → CCl₄ + 4HCl

Now each side has four hydrogen atoms. Now we can balance the chlorine.  The product side has a total of eight chlorine atoms (four from the CCl₄ and four from the four molecules of HCl), so we need eight chlorine atoms on the reactant-side of the equation. Because elemental chlorine is a diatomic molecule, we need a total of  four chlorine molecules to get a total of eight chlorine atoms. We add another 4 in front of the Cl₂ reactant:

CH₄ + 4Cl₂ → CCl₄ + 4HCl

Now we double check: each side has one carbon atom, four hydrogen atoms, and eight chlorine atoms. Yes, the chemical equation is balanced.

---

Quiz Yourself: More Practice Balancing Equations

(Back to the Top)

---

5.3 Quantitative Relationships Based on Chemical Equations

A balanced chemical equation not only describes some of the chemical properties of substances—by showing us what substances react with what other substances to make what products—but also shows numerical relationships between the reactants and the products. The study of these numerical relationships is called stoichiometry. The stoichiometry of chemical equations revolves around the coefficients in the balanced chemical equation because these coefficients determine the molecular ratio in which reactants react and products are made. It is very similar to cooking.  For example, to make a hamburger, for each hamburger patti, you need to have two slices of bread for the bun.  Thus, the ratio of bread to hamburger is 2 to 1.

Consider the following balanced chemical equation:

2C₂H₂ + 5O₂ → 4CO₂ + 2H₂O

The coefficients on the chemical formulas give the ratios in which the reactants combine and the products form. Thus, we can make the following statements and construct the following ratios:

STATEMENT:

This statement can then be represented mathematically into ratios that represent these written relationship statements.

Other relationships are possible; in fact, 12 different ratios can be constructed from this balanced chemical equation. In each ratio, note that the unit is molecules. Chemical reactions describe the number of molecules of one substance required to react with or produce another substance. Any of these fractions can be used as a conversion factor to relate an amount of one substance to an amount of another substance. For example, suppose we want to know how many CO₂ molecules are formed when 26 molecules of C₂H₂ are reacted.

As usual with a conversion problem, we start with the amount we are given — 26 C₂H₂ — and multiply it by a conversion factor that cancels out our original unit and introduces the unit we are converting to—in this case, CO₂.

Thus, we have two choices for our conversion factor

To cancel C₂H₂, we need to make sure that this unit is on the bottom of our convesion factor.  Thus, we can set up our conversion equation as follows:

Thus, 52 molecules of CO₂ are formed when we start with 26 molecules of C₂H₂.  Note that with this conversion factor, that we could have simplified our conversion factor prior to completing the multiplication and division steps, as follows:

This application of stoichiometry is extremely powerful in its predictive ability, as long as we begin with a balanced chemical equation. Without a balanced chemical equation, the predictions made by simple stoichiometric calculations will be incorrect.

(Back to the Top)

---

5.4 Some Types of Chemical Reactions

Although there are untold millions of possible chemical reactions, most can be classified into a small number of general reaction types. Classifying reactions has two purposes: it helps us to recognize similarities among them, and it enables us to predict the products of certain reactions. In this chapter, we will discuss five major categories of chemical reactions:  (1) Combination (or Synthesis) Reactions, (2) Decomposition Reactions, (3) Single Replacement Reactions, (4) Double Replacement Reactions, and (5) Redox Reactions.  Note that a particular reaction may fall into more than one of the categories that we will define in this book.

(1) Combination (or Synthesis) Reactions

A combination (or synthesis) reaction is a chemical reaction is a building reaction, where two or more elements or compounds combine to make a single compound.

The general equation for a combination reaction is:

A + B → AB

An example of a combination reaction is:

4Fe(s) + 3O₂(g) → 2Fe₂O₃(s)

In this reaction, the elements iron (Fe) and oxygen (O₂) combine to produce iron III oxide (Fe₂O₃).  Note that combination reactions do not have to combine elements together, however. Combination reactions can also combine compounds together to form larger compounds. The chemical equation:

Fe₂O₃(s) + 3SO₃(s) → Fe₂(SO₄)₃(s)

shows a combination reaction in which iron III oxide (Fe₂O₃) combines with three molecules of sulfur trioxide (SO₃) to make iron III sulfate [Fe₂(SO₄)₃].

---

(2) Decomposition Reactions

A decomposition reaction is the reverse of a combination reaction. In a decomposition reaction, a single substance is converted or broken down into two or more products. A general equation for decomposition reactions is:

AB → A + B

For example, the equation below is a decomposition reaction that occurs when Sodium Bicarbonate (NaHCO₃) is exposed to heat:

2NaHCO3(s) → Na2CO3(s) + CO2(g) + H2O(ℓ)

Another example is the decomposition of KClO₃:

2KClO₃(s) → 2KCl(s) + 3O₂(g)

This reaction can be used to generate small amounts of oxygen in the chemistry lab.

(Back to the Top)

---

(3) Single Replacement (or Single Displacement) Reactions

Single replacement (or displacement) reactions occur when an element (most frequently a metal) replaces another element from a compound. They can occur in two forms: cationic exchange or anionic exchange.  In cationic exchanges, the positive ions (cations) of the equation change place.  In anionic exchanges, the negative ions (anions) change place. Note that single replacement reactions are often also redox reactions, and thus, we will revisit this reaction type in that section.

The general equation for a cationic single replacement reaction is:

A + BC → AC + B

For a cationic exchange reaction, A represents a cation that replaces cation B in the product, AC. An example of a cationic exchange reaction is:

2 Ag(s) + 2 HCl(aq) →  H₂(g)  +  2 AgCl(s)

In this reaction, the silver replaces the hydrogen cation in the hydrochloric acid to form silver chloride in the final product.

For anion exchange reactions, the following general reaction can be used:

D + BC → BD + C

An example of an anionic exchange reaction is:

3 F₂(g)  +  2 FeCl₃(aq)  →  2 FeF₃(aq)  +  3 Cl₂(g)

In this reaction, flourine replaces chlorine anion in the iron III chloride to produce iron III fluoride.

---

(4) Double Replacement (or Displacement) Reactions

Double replacement (or displacement) reactions occur when two chemical groups substitute for each other (change partners) in their respective compounds.

A general equation for a double replacement reaction is:

AB   +   CD   →   AD   +   CB

Two major types of double replacement reactions are  Acid-Base Neutralization reactions and Precipitation reactions.

Acid-Base Neutralization Reactions

In an acid base neutralization reaction, an acid is combined with a base to form a salt and water.

Precipitation Reactions

Precipitation reactions occur when cations and anions in aqueous solution combine to form an insoluble ionic solid called a precipitate. Whether or not such a reaction occurs can be determined by using the solubility rules for common ionic solids. Because not all aqueous reactions form precipitates, one must consult the solubility rules before determining the state of the products The ability to predict these reactions allows scientists to determine which ions are present in a solution, and allows industries to form chemicals by extracting components from these reactions.

Precipitates are insoluble ionic solid products of a reaction, formed when certain cations and anions combine in an aqueous solution. The determining factors of the formation of a precipitate can vary. Some reactions depend on temperature, such as solutions used for buffers, whereas others are dependent only on solution concentration. The solids produced in precipitate reactions are crystalline solids, and can be suspended throughout the liquid or fall to the bottom of the solution. The remaining fluid is called supernatant liquid. The two components of the mixture (precipitate and supernate) can be separated by various methods, such as filtration, centrifuging, or decanting.

Figure 5.3: Above is a diagram of the formation of a precipitate in solution.

(Back to the Top)

---

The use of solubility rules require an understanding of the way that ions react. Most precipitation reactions are single replacement reactions or double replacement reactions. A double replacement reaction occurs when two ionic reactants dissociate and bond with the respective anion or cation from the other reactant. The ions replace each other based on their charges as either a cation or an anion. This can be thought of as “switching partners”; that is, the two reactants each “lose” their partner and form a bond with a different partner:

Figure 5.4: A double replacement reaction

A double replacement reaction is specifically classified as a precipitation reaction when the chemical equation in question occurs in aqueous solution and one of the of the products formed is insoluble and forms a solid product. An example of a precipitation reaction is given below:

CdSO4(aq) + K₂S(aq) → CdS(s) + K₂SO₄(aq)

Both reactants are aqueous and one product is solid. Because the reactants are ionic and aqueous, they dissociate and are therefore soluble. However, CdS is insoluble and precipitate out of solution to form a solid product.  There are six solubility guidelines that you can use to help you predict which molecules will form a solid and enable you to identify a precipitation reaction.

Solubility Rules

Whether or not a reaction forms a precipitate is dictated by the solubility rules. These rules provide guidelines that tell which ions form solids and which remain in their ionic form in aqueous solution. The rules are to be followed from the top down, meaning that if something is insoluble (or soluble) due to rule 1, it has precedence over a higher-numbered rule.

1. Salts formed with group 1 cations and NH⁴⁺ cations are soluble. There are some exceptions for certain Li⁺ salts.
2. Acetates (C₂H₃), nitrates (NO₃⁻), and perchlorates (ClO₄⁻) are soluble.
3. Bromides, chlorides, and iodides are soluble.
4. Sulfates (SO₄^2-) are soluble with the exception of sulfates formed with Ca²⁺, Sr²⁺, and Ba²⁺. These salts are insoluble.

5. Salts containing silver, lead, and mercury (I) are insoluble.
6. Carbonates (CO₃²⁻), phosphates (PO₄³⁻), sulfides, oxides, and hydroxides (OH⁻) are insoluble. Sulfides formed with group 2 cations and hydroxides formed with calcium, strontium, and barium are exceptions.

Practice Problems

Write the net ionic equation for the potentially double displacement reactions. Make sure to include the states of matter and balance the equations.

1. Fe(NO₃)₃(aq) + NaOH(aq) →
2. Al₂(SO₄)₃(aq) + BaCl₂(aq) →
3. HI(aq) + Zn(NO₃)₂(aq) →
4. CaCl₂(aq) + Na₃PO₄(aq) →
5. Pb(NO₃)₂(aq) + K₂SO₄(aq)

Canceling out spectator ions leaves the net ionic equation:

2. From the double replacement reaction, the products are AlCl₃ and BaSO₄. AlCl₃ is soluble because it contains a chloride (rule 3); however, BaSO₄ is insoluble: it contains a sulfate, but the Ba²⁺ ion causes it to be insoluble because it is one of the cations that causes an exception to rule 4. The ionic equation is (after balancing):

Canceling out spectator ions leaves the following net ionic equation:

3. From the double replacement reaction, the products HNO₃ and ZnI₂ are formed. Looking at the solubility rules, HNO₃ is soluble because it contains nitrate (rule 2), and ZnI₂ is soluble because iodides are soluble (rule 3). This means that both the products are aqueous (i.e. dissociate in water), and thus no precipitation reaction occurs.

4. The products of this double replacement reaction are Ca₃(PO₄)₂ and NaCl. Rule 1 states that NaCl is soluble, and according to solubility rule 6, Ca₃(PO₄)₂ is insoluble. The ionic equation is:

After canceling out spectator ions, the net ionic equation is given below:

5. The first product of this reaction, PbSO₄, is soluble according to rule 4 because it is a sulfate. The second product, KNO₃, is also soluble because it contains nitrate (rule 2). Therefore, no precipitation reaction occurs.

(Back to the Top)

---

(5) Oxidation and Reduction (Redox) Reactions

An oxidation-reduction (redox) reaction is a type of chemical reaction that involves a transfer of electrons between two atoms or compounds.  The substance that loses the electrons is said to be oxidized, while the substance that gains the electrons is said to be reduced. The change in electron composition can be evaluated in the change of the oxidation state (or number) of an atom. Therefore, an oxidation-reduction reaction is any chemical reaction in which the oxidation state (number) of a molecule, atom, or ion changes by gaining or losing an electron. We will learn how to evaluate the oxidation state of a molecule within this section. Overall, redox reactions are common and vital to some of the basic functions of life, including photosynthesis, respiration, combustion, and corrosion or rusting.

As shown in figure XX, an easy mnemonic for helping you remember which member gains electrons and which member loses electrons is ‘LEO the lion says GER’, where LEO stands for Lose Electrons = Oxidized and GER stands for Gain Electrons = Reduced.

Once you have mastered calculating oxidation states, you can start evaluating chemical reactions to determine if they are oxidation-reduction reactions.

Redox reactions are comprised of two parts, a reduced half and an oxidized half, that always occur together. The reduced half gains electrons and the oxidation number decreases (or becomes less positive), while the oxidized half loses electrons and the oxidation number increases (becomes more positive). There is no net change in the number of electrons in a redox reaction. Those given off in the oxidation half reaction are taken up by another species in the reduction half reaction.

A good example of a redox reaction is the thermite reaction, in which iron atoms in ferric oxide lose (or give up) O atoms to Al atoms, producing Al₂O₃.

To recognize redox reactions, begin by determining the oxidation states of each atom in the reaction on both the left and the right sides of the equation. Then determine of the oxidation state of any of the atoms changes from the reactant to the product side.  If so, then the reaction is a redox reaction, and you can determine which compound is oxidized (loses electrons) and which is reduced (gains electrons). For example, if we evaluate the thermite reaction above:

Overall in this reaction, the aluminum is oxidized to aluminum oxide, and the iron in the iron III oxide is reduced to elemental iron. Notice that there is no change to the oxidation state of oxygen.

The two species that exchange electrons in a redox reaction are given special names. The ion or molecule that accepts electrons (or becomes reduced during the reaction) is called the oxidizing agent; by accepting electrons it causes the oxidation of another compound or element. In the thermite reaction above, the iron III oxide is the oxidizing agent. Conversely, the species that donates electrons is called the reducing agent; when the reaction occurs, it reduces the other species. Thus, in the thermite reaction, the aluminum is the reducing agent. In other words, the substance that is oxidized is the reducing agent and the substance that is reduced is the oxidizing agent.

Single replacement reactions are often also redox reactions. A good indicator of a redox reaction is the appearance of an elemental form of a substance on one side that is converted into a compound on the other side. Another common redox reaction is a combustion reaction.

(Back to the Top)

---

Combustion Reactions



C_xH_y + O₂ → CO₂ + H₂O

O

Combustion reactions almost always involve oxygen in the form of O₂, and are almost always exothermic, meaning they produce heat. Chemical reactions that give off light and heat and light are colloquially referred to as “burning.” Complete combustion of carbon compounds results in the production of carbon dioxide (CO₂) and water (H₂O). Note that carbon can exist in a range of oxidation states, typically from -4 to +4. The burning of fuels that provides the energy to maintain our civilization and the metabolism of foods that furnish the energy that keeps us alive both involve redox reactions.

All combustion reactions are also redox reactions.

C_xH_y + O₂ → CO₂ + H₂O

One example is the burning of acetylene (C₂H₂) in torches:

2C₂H₂ + 5O₂ → 4CO₂ + 2H₂O

Oxygen (in its elemental form) is a crucial reactant in combustion reactions, and it is also present in the products. Combustion reactions can be evaluated for their redox potential, as we did for the thermite reaction above.

Overall in combustion reactions, the hydocarbon (in this case, acetylene) is oxidized by molecular oxygen to produce carbon dioxide and water. In the process, oxygen is reduced.

In respiration, the biochemical process by which the oxygen we inhale in air oxidizes foodstuffs to carbon dioxide and water, redox reactions provide energy to living cells. A typical respiratory reaction is the oxidation of glucose (C₆H₁₂O₆), a simple sugar.

C₆H₁₂O₆ + 6O₂ → 6CO₂ + 6H₂O

(Back to the Top)

---

A Closer Look at the Importance of Redox Reactions

Organic chemists use a variety of redox reactions. For example, potassium dichromate (K₂Cr₂O₇) is a common oxidizing agent that can be used to oxidize alcohols (symbolized by the general formula R-OH, where R can be any group, and the OH represents the alcohol functional group). The product of the reaction depends on the location of the OH functional group in the alcohol molecule, the relative proportions of alcohol and the dichromate ion, and reaction conditions such as temperature. If the OH group is attached to a terminal carbon atom and the product is distilled off as it forms, the product is an aldehyde, which has a terminal carbonyl group (C=O). One example is the reaction used by the Breathalyzer to detect ethyl alcohol (C₂H₅OH) in a person’s breath:

3C₂H₅OH + Cr₂O₇²⁻ + 8H⁺ → 3CH₃CHO + 2Cr³⁺ + 7H₂O

Figure 5.3 Drinkers Learn Their Limit Using a Standard Breathalyzer Test
Picture from: KOMUnews

---

In food chemistry, the substances known as antioxidants are reducing agents. Ascorbic acid (also known as vitamin C; C₆H₈O₆) is thought to prevent potentially damaging oxidation of living cells. In the process, it is oxidized to dehydroascorbic acid (C₆H₆O₆).

In the stomach, ascorbic acid reduces the nitrite ion (NO²⁻) to nitric oxide (NO):

C₆H₈O₆ + 2H⁺ + 2NO²⁻ → C₆H₆O₆ + 2H₂O + 2NO

If this reaction did not occur, nitrite ions from foods would oxidize the iron in hemoglobin, destroying its ability to carry oxygen.

Tocopherol (vitamin E) is also an antioxidant. In the body, vitamin E is thought to act by scavenging harmful by-products of metabolism, such as the highly reactive molecular fragments called free radicals. In foods, vitamin E acts to prevent fats from being oxidized and thus becoming rancid.

Finally, and of greatest importance, green plants carry out the redox reaction that makes possible almost all life on Earth. They do this through a process called photosynthesis, in which carbon dioxide and water are converted to glucose (C₆H₁₂O₆). The synthesis of glucose requires a variety of proteins called enzymes and a green pigment called chlorophyll that converts sunlight into chemical energy (Figure 5.4). In this reaction, carbon dioxide is reduced to form glucose (C₆H₁₂O₆), and water is oxidized to oxygen gas. Other reactions convert the glucose (C₆H₁₂O₆) to more complex carbohydrates, plant proteins, and oils. The chemical reaction that occurs is as follows:

6CO₂ + 6H₂O → C₆H₁₂O₆ + 6O₂

Figure 5.4 Diagram of Photosynthesis. In photosynthesis, light energy from the sun is harvested by the chlorophyll pigments primarily in the plant leaves where it is used to convert carbon dioxide and water into sugar (glucose).

Image provided from: Masroor.nida.ns

(Back to the Top)

---

5.5 Focus on the Environment – Air Pollution

Understanding and monitoring air quality is essential to atmospheric scientists to help reduce emissions, protect human health and the environment. In this learning module, we will learn about air pollutants, their sources, and the effects on the environment and our respiratory systems.

Figure 5.5 Air Pollution in Hong Kong. On two cloud-free days, the haze situation can differ dramatically depending on the season and on the direction of the wind. Source: Tokyoahead

---

Composition of the Atmosphere

The air is made up of many different gases. To give you an idea of what air actually consists of watch this video!

Video Tutorial on the Composition of Air

The first, nitrogen, is the largest constituent of the atmosphere. If the air were made of 1000 parts, nitrogen would call for 780 parts, or 78%. Nitrogen is really important to us because it helps plants to gain minerals from the soil for plant growth. The next most common gas that is in air is oxygen. Oxygen makes up 209 parts, or 20.9% of our air. Oxygen is important for many things. We need it to breath, but it is also needed for fires. The only problem is with oxygen, if you have too much of it, oxygen is extremely reactive. Things could combust if you have an oxygen-rich environment, so having the nitrogen in our air balances it out and gives us the right percentage of oxygen and nitrogen together to make air safe to breath and be around.

The next gas in the air is called argon. Argon does not do much for us in the atmosphere, but we have 9 parts, or 0.9% in the air. Argon is a gas that can be placed in a tube with an electric current to create a purple hue in a neon sign. Next, we have a gas that we hear a lot about these days, which is carbon dioxide. This gas is one of the trace gases and is found in small concentrations in the atmosphere. Carbon dioxide is a gas that we exhale when we breathe. It is also taken in by plants to create the plant’s structure. Carbon dioxide is a greenhouse gas and allows incoming solar radiation to pass through the atmosphere, but traps outgoing or reflected sunlight to cause a warming effect in our atmosphere. Trace gases, including carbon dioxide, make up 1 part, or 0.1% of the air. Other trace gases include ozone, nitrogen oxide, methane, helium, neon, water vapor, and several others.

Figure 5.6. Composition of the Atmosphere.  Most of our atmosphere, 99%, is made of oxygen (O₂) at 21% and nitrogen (N₂) at 78%. Greenhouse gases, like water vapor, carbon dioxide and methane are vitally important for keeping our planet warm. Although these gases are found in small concentrations, they are vitally important in maintaining a globally averaged temperature of 59^oF.

---

Pollutants

What is air pollution? It is not only chemicals in the atmosphere, but chemicals that have bad health effects. Since we are breathing it in, it is going to affect our health, lung function, and can lead to increased cancer risks. If the chemicals are affecting us negatively, we call them pollutants. Please watch the following video tutorial describing atmospheric pollutants.

Air Pollution Tutorial

Primary pollutants are emitted directly into the atmosphere by a particular source. These include volatile organic compounds (VOCs) such as gases from evaporating gasoline, carbon monoxide (CO), which is an odorless gas that is produced by oxidation reactions, nitrogen oxide (NO), nitrogen dioxide (NO₂), sulfur dioxide (SO₂), particulate matter (PM), and lead (Pb) which used to be a common additive in gasoline and other industrial formulations, such as paint. Lead pollution will be discussed in further detail in Chapter 7.

Primary pollutants can combine with other chemicals in the atmosphere and produce secondary pollutants.

Figure 5.7 Diagram of primary and secondary pollutants. Diagram by: Paul Anderson

As seen in chapter 3, a number of these primary pollutants can react to form atmospheric acids that are the cause of acid rain. Examples from chapter 3 included NO_x compounds that react to produce nitric acid (HNO₃), and SO₂ that reacts to produce sulfuric acid (H₂SO₄).  Ozone is another secondary pollutant that is formed through chemical reactions between NO₂, VOCs, and sunlight.

1. NO₂ from vehicle exhaust, is photolyzed by ultraviolet (UV) radiation (hν) from the sun and decomposes into NO and an oxygen radical:

2. The oxygen radical then reacts with an atmospheric oxygen molecule to create ozone, O₃:

3. Under normal conditions, O₃ reacts with NO, to produce NO₂  and an oxygen molecule:

This is a continual cycle that leads only to a temporary increase in net ozone production. To create photochemical smog on the scale observed in Los Angeles, the process must also include volatile organic compounds (VOCs).

4. VOC’s (indicated as RH, where R is a placeholder for a more complicated carbon-oxygen containing structures) react with hydroxide in the atmosphere to create water and a reactive VOC molecule:

5. The reactive VOC can then bind with an oxygen molecule to create an oxidized VOC:

6. The oxidized VOC can now bond with the nitrogen oxide produced in the earlier set of equations to form nitrogen dioxide and a reactive VOC molecule:

In the second set of equations (4-6), the nitrogen oxide, produced in equation 1, is oxidized in equation 6 without the destruction of any ozone. This means that in the presence of VOCs, in equation 3, is essentially eliminated, leading to a large and rapid build up in the photochemical smog in the lower atmosphere.

The EPA has an interactive chart evaluating ground level ozone concentrations over an 8 hour period. Please click on the link below. Once on the site, mouse over the different hours of the day at the top of the page to see how pollution levels change. What is the high point of pollution? Why do you think that this is the case?



Ground Level Ozone Concentrations over an 8 hr Period



In the morning, NO and VOC concentrations rise, as people fill their cars with gas and drive to work. By midmorning , VOC’s begin to oxidize NO into NO₂, thus reducing their respective concentrations. At midday, NO₂ concentrations peak just before solar radiation becomes intense enough to photolyze the NO₂ bond, releasing an oxygen atom that quickly gets converted into O₃. By late afternoon, peak concentrations of photochemical smog are present.

Ozone can be helpful or harmful to our health and the environment. In the stratosphere, ozone is produced naturally where it blocks harmful ultraviolet rays from the sun. This is an example of “good” ozone. In the troposphere, ground-level ozone largely contributes to smog. This is “bad” ozone.

Figure 5.8. A vertical profile showing atmospheric ozone, which includes tropospheric and stratospheric ozone levels. Note that high levels of surface ozone in urban and rural areas are largely due to human pollution.

---

Improving Air Quality

A wide array of harmful health effects have been attributed to air pollution including respiratory diseases such as asthma and COPD, cardiovascular diseases, adverse pregnancy outcomes (such as preterm birth) and even death. Air pollution can be improved and controlled air through regulation. The Clean Air Act (1970) in the United States was able to reduce pollutants and save lives. As seen in chapter 3 with the control of acid rain, technology is able to scrub those pollutants out of the air before it is released. The Clean Air Act put strict standards on certain pollutants so that industries are limited on how many pollutants they can put into the atmosphere.

The Clean Air Act requires the Environmental Protection Agency (EPA) to set National Ambient Air Quality Standards (NAAQS) for pollutants considered harmful to public health and the environment. The EPA has set standards for six criteria pollutants which include: carbon monoxide (CO), lead (Pb), nitrogen dioxide (NO₂), ozone (O₃), particulate matter (PM), and sulfur dioxide (SO₂). Follow the link to learn more about the criteria pollutants and the concentrations at which they are considered by the EPA to be unsafe.

Air Quality Index

The Air Quality Index (AQI) is a color-coded scale that ranges from 0 – 500 and evaluates the health quality of the air around us. A rating below 50 indicates good air quality, whereas over 150 indicates unhealthy conditions for all populations.   To learn more about the AQI, watch this next video.

Air Quality Index

The United States EPA has a real time website entitled AirNow where you can look up air quality for any state within the United States. In 2007, the US Embassies in China also established a World Air Quality Index Project that is helping monitor air quality world wide  region in the world. This project is currently providing air quality information in over 80 countries with over 10,000 monitoring stations. The United Nations Environment Programme partners with countries from around the world to address health issues and find solutions for air pollution.

Suggested Activity: Have your students download the following air_pollution_in class activity.  Introduce the Smog City Program in class and describe how to use the various controls. Have your students complete parts 1 and 2 as homework assignments. Once complete review the assignment with an in-class discussion.

5.6 Chapter Summary

To ensure that you understand the material in this chapter, you should review the meanings of the following bold terms in the following summary and ask yourself how they relate to the topics in the chapter.

Scientific laws are general statements that apply to a wide variety of circumstances. One important law in chemistry is the law of conservation of matter, which states that in any closed system, the amount of matter stays constant.

Chemical equations are used to represent chemical reactions. Reactants change chemically into products. The law of conservation of matter requires that a proper chemical equation be balanced. Coefficients are used to show the relative numbers of reactant and product molecules.

In stoichiometry, quantities of reactants and/or products can be related to each other using the balanced chemical equation. The coefficients in a balanced chemical reaction are used to devise the proper ratios that relate the number of molecules of one substance to the number of molecules of another substance.

Chemical reactions can be classified by type. Combination reactions (also called synthesis reactions) build or make a substance from other substances, whereas, decomposition reactions break one substance down into multiple substances.

Single replacement (or displacement) reactions occur when an element (most frequently a metal) replaces another element from a compound. They can occur in two forms: cationic exchange or anionic exchange.  In cationic exchanges, the positive ions (cations) of the equation change place.  In anionic exchanges, the negative ions (anions) change place. Note that single replacement reactions are often also redox reactions.

Double replacement (or displacement) reactions occur when two chemical groups substitute for each other (change partners) in their respective compounds. Double replacement reactions can be of two major types:  (1) precipitation reactions wherein, at least one of the products forms a solid precipitate during the reaction, and (2) acid-base neutralization reactions, wherein an acid is neutralized by a base to form a salt and water. The solubility rules are used to determine if products in a double displacement reaction will be insoluble and precipitate from the reaction mixture. Both precipitation and acid-base neutralization reactions can be written as net ionic equations.

Oxidation reactions are reactions in which an atom loses an electron. Reduction reactions are reactions in which an atom gains an electron. These two processes always occur together, so they are collectively referred to as oxidation-reduction (or redox) reactions. The species being oxidized it called the reducing agent, while the species being reduced is the oxidizing agent. Combustion reactions are a type of redox reaction that combine molecular oxygen with the atoms of another reactant.

Oxidation-reduction reactions are common in organic and biological chemistry. Respiration, the process by which we inhale and metabolize oxygen, is a series of redox reactions. In the absence of oxygen, redox reactions still occur in a process called anaerobic metabolism. Antioxidants such as ascorbic acid also play a part in the human diet, acting as reducing agents in various biochemical reactions. Photosynthesis, the process by which plants convert water and carbon dioxide to glucose, is also based on redox reactions.

(Back to the Top)

---

5.7 References

1. UC Davis, Libretexts. (2016) Chemistry. https://chem.libretexts.org/Core/Inorganic_Chemistry/Descriptive_Chemistry/Main_Group_Reactions/Reactions_in_Aqueous_Solutions/Precipitation_Reactions
2. Anonymous. (2012) Introduction to Chemistry: General, Organic, and Biological (V1.0). Published under Creative Commons by-nc-sa 3.0. Available at: http://2012books.lardbucket.org/books/introduction-to-chemistry-general-organic-and-biological/index.html
3. Brown, T., Riemer, N., Snodgrass, E., and Ortiz, A.  (2015) Air Pollution Learning Module. Published under Creative Commons ShareAlike 4.0 International License. Available at: https://www.atmos.illinois.edu/~nriemer/education/air_pollution_module.pdf
4. California State University Affordable Learning Solutions (2014) Smog Module in Physical and Theoretical Chemistry. Published by LibreTexts under Creative Commons ShareAlike 3.0 License. Available at: https://chem.libretexts.org/Textbook_Maps/Physical_and_Theoretical_Chemistry_Textbook_Maps/Supplemental_Modules_(Physical_and_Theoretical_Chemistry)/Kinetics/Case_Studies%3A_Kinetics/Smog
